ELC Lighting

dmXLAN Node 3 Wall

The dmXLAN Node 3 is a compact DMX / Ethernet node featuring 3 fully isolated, fully programmable DMX ports, a dual 100 Mbit Ethernet switch, and an integrated user interface with display.

It provides 3 bi-directional, optically isolated DMX ports, configurable as DMX/RDM inputs or outputs, and supports advanced functions such as data splitting, merging (HTP / Priority), softpatching, and backup when programmed with the free ELC dmXLAN v4 software.

The Node 3 is available in multiple form factors, including a PoE-powered version, allowing data and power over a single Ethernet cable for a quick and clean installation.

Find a distributor near you
View manual

Need firmware, software or downloads?

Head to Support for manuals, firmware, software tools (including version history), and help with troubleshooting.

Features

  • Power over Ethernet (optional)
  • Multiple form factors (Truss mount, surface mount, recessed wall mount and DIN)
  • 3 Bi-directional DMX ports
  • RDM compatible with RDM proxy support (output only)
  • Supports sACN, Art-Net & Shownet
  • Remote (offline) programming and monitoring and fixture parameter override using dmXLAN v4 or Fixture Tester
  • DMX Output normal, HTP, Priority merging, Softpatch (channel by channel), programmable merging with DMX channel control
  • Support for WYSIWYG, Depence, Capture, Vision and other visualization software
  • Local control via LCD display with rotary encoder and pushbutton selector (excluding DIN version)
Protocols
    ArtNet.svg

    Art-Net

    Broadcast DMX512 data across IP networks.
    sACN.svg

    sACN

    Transmit DMX512 data efficiently with multicast capabilities.
    RDM.svg

    RDM

    Bi-directional communication for configuring and monitoring connected devices.
Highlights
    laptop.svg

    dmXLAN compatible

    dmXLAN allows you to configure, control, test, and monitor network and lighting devices, without the need for an external lighting console.
    ethernet-port.svg

    PoE powered

    Optional PoE power allows a single Ethernet cable to carry both data and power.
    route.svg

    Advanced softpatching

    Merge up to three universes with full channel‑by‑channel configurability and external merge control.
Order details


Article numbers:


ELC-DLN3T – Truss mount (mains powered)

ELC-DLN3TPOE – Truss mount (PoE powered)

ELC-DLN3S – Surface mount (PoE Powered)

ELC-DLN3W – Recessed wall mount (PoE powered)

ELC-DLN3DIN – DIN version (9-24V DC powered)
