AC612 Button and Fader

The AC612 Button and Fader is a compact, straightforward button/fader playback panel designed for quick, reliable recall of pre-recorded DMX looks. With 8 dedicated buttons, 3 faders and convenient terminal connections, it is a practical choice for architectural lighting, fixed installations, show control, and anywhere you want simple hands-on playback without a full console.

Ideal for standalone use or as part of a larger system, the AC612 Button and Fader captures data directly from a DMX signal and stores it in 12 memories of up to 512 channels each. Every memory can be a single scene or a chase with its own step length and timing, giving you flexible playback for both static states and dynamic effects. For smooth control on site, the master fade buttons let you bring lighting levels up or down from 0% to 200%. Programming and editing is quick and easy using ELC’s free AC612 editor software.

Find a distributor near you
View manual

Need firmware, software or downloads?

Head to Support for manuals, firmware, software tools (including version history), and help with troubleshooting.

Features

  • Externally powered (9-24V DC via screw terminals)
  • 1 Output DMX port (screw terminals)
  • 1 Input DMX port (screw terminals)
  • Captures and records lighting data directly from a DMX signal
  • 8 playback memories, each storing up to 512 DMX channels
  • Each memory can be a single scene or a chaser (total capacity: 126 chaser steps)
  • Per-step chaser timing with stored step length and crossfade times
  • Master up/down fade buttons for smooth level control from 0% to 200%
  • Simple programming and editing using the free ELC AC612 editor software
Highlights
    laptop.svg

    AC612 Editor

    Simple programming and editing using the free ELC AC612 editor software.
    map-pin.svg

    Local Control

    The AC612-series can operate as a standalone DMX controller.
    chart-no-axes-gantt.svg

    Per-step Chaser Control

    Store chase steps with individually adjustable step times and crossfade values for smooth, consistent transitions.
Order details


Article numbers:

ELC-AC612XUB - AC612 Button
ELC-AC612XUF - AC612 Fader
ELC-AC612XUBF - AC612 Button and Fader
ELC-AC612DIN - AC612 DIN
