DT125
The DT125 is a compact and reliable DMX splitter designed to strengthen and distribute a single DMX line across five fully isolated outputs. Supporting bi‑directional RDM communication, it ensures clean and stable signal flow in small to medium‑sized lighting networks where a simple daisy chain is not sufficient.
With full galvanic isolation and boosted DMX/RDM outputs, the DT125 protects your controller and connected fixtures while providing dependable signal distribution for installations, theatres, and live event applications.
Need firmware, software or downloads?
Head to our support section for manuals, firmware, software tools (including version history), and help with troubleshooting.
Features
- 1 Input DMX port, with DMX‑thru (1x XLR 5-pin male, 1x XLR 5-pin female)
- 5 Output DMX port (XLR 5-pin female)
- Fully RDM‑compatible for bi-directional communication
- Boosted DMX/RDM outputs, supporting up to 32 devices per output
- Optocoupler‑isolated inputs and outputs for maximum electrical protection
- Status LEDs confirming valid DMX
- USB port for easy firmware updates
Order details
Article numbers:
ELC-DT125 - DT125 DMX/RDM Splitter
ELC-DT125_FI - DT125 DMX/RDM Splitter (fully isolated)
ELC-DT125DIN - DT125 DMX/RDM DIN-mountable Splitter
ELC-DT125DIN_FI - DT125 DMX/RDM DIN-mountable Splitter (fully isolated)
Accessoiries:
ELC-RMKIT - Rackmount kit
